The Lion Head Locks BEAUFORT is a modern, sophisticated digital deadbolt that is ideal for residential applications.

The BEAUFORT offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The BEAUFORT is rated IP55 (outside only), so it is best suited for applications where there is some protection from the elements.

It is supplied with a 60/70mm adjustable deadbolt.

The BEAUFORT is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material:  Zinc alloy
Colour:  Black
IP Rating: IP55 (exterior assembly only)
Dimensions:  140mm x 60mm x 16mm (front), 155mm x 68mm x 28mm (back)
Unlocking Methods:  APP, Fingerprint, PIN code, Card, Key
User Capacity:  200 Fingerprint, 150 PIN code, 200 Card
Key Override:  Yes (track style key)
Batteries:  4 X AA alkaline (not supplied)
Battery Life:  Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Supplied Lock/Latch:  LHL 60/70mm adjustable tubular deadbolt
Other Lock/Latch Options:  Not applicable
Working Temperature:  -25C – 60C degrees
Working Humidity:  0% – 95% RH
Door Thickness:  35mm – 55mm
Suitable For:  Wooden and metal doors

The Rock is a durable and powerful Prox Reader from Lion Head Locks!  Engineered for high-security access control, The ROCK offers multiple unlocking methods, including BLE, Wi-Fi (via Gateway sold seperately), and Mifare cards, making it perfect for residential, office, Airbnb, and apartment projects.

Crafted from tough zinc alloy and designed with an IP66 rating, The ROCK is built to withstand harsh conditions while providing reliable performance. With the capacity to store up to 1,000 cards and support for 13.56MHz Mifare and M1 cards, it’s ideal for multi-user environments that demand both flexibility and security.

Powered by 12V and operating in a wide range of temperatures (-20°C to 60°C), The ROCK ensures dependable performance in any climate. Its sleek, compact design makes it an easy addition to any door, and its Bluetooth 4.1 technology ensures seamless integration with mobile apps for remote access control.

If you’re looking for a rugged, reliable solution for secure access, The ROCK is the perfect choice.

Material: Zinc alloy
Colour: Silver
Panel Sizes: 103mm X 48mm X 19mm
Unlock method: wifi App, Card, Bluetooth
Power: 12V
IP Rating: IP66
Working Temperature: -20C – 60C
Working Humidity: 0% – 85%
Card Types: 13.56MHz MiFare, M1 Card
Card Capacity: 1000

The TITAN Digital Keypad from Lion Head Locks is a modern, slimline, standalone keypad with integrated TTLock technology.

The TITAN offers multiple access options, including via the TTLock APP, Bluetooth, PIN code and RFID Fob/Card, as well as remote access by the Lion Head Locks optional gateway.

The TITANcan be used with electric strikes, magnetic latches and motorized gates.

Made from durable zinc alloy, and with an IP66 rating, the TITAN is suitable for residential and commercial applications, and it offers the perfect solution for applications where space is limited.

Material: Zinc Alloy
Lock Dimensions: 148mm X 43.5mm X 22mm
Projection: 22MM
Field Changeable: NA
Power: 12V
Working Current: <80mA
Lock Output Load: <2A
Working Temperature: -20C – +60C
Working Humidity: 0% – 85%
Pin Capacity: 150 Custom, 150 Dynamic
Card Types: 13.56MHz Mifare Card, M1 Card
Card Capacity: 1000
Unlocking Methods: BLE, WiFi (via Gateway sold seperately), Mifare Card
IP Rating: IP66

The OSCAR Digital Keypad from Lion Head Locks is a sleek, standalone keypad with integrated TTLock technology. At only 68mmwide, the OSCAR offers a slightly slimmer profile than the BOURKE and the MILTON.

The OSCAR offers multiple access options, including via the TTLock APP, Bluetooth, PIN code and RFID Fob/Card, as well as remote access by the Lion Head Locks optional gateway.

The OSCAR can be used with electric strikes, magnetic latches and motorized gates.

Made from durable zinc alloy, and with an IP66 rating, it is built to withstand tough conditions. With standard 82mm vertical mounting centres, it is suitable for residential and commercial applications, including office environments.

Material:  Zinc Alloy
Lock Dimensions:  149mm X 68mm X 25mm
Projection:  25MM
Field Changeable:  NA
Power:  12V
Working Current:  <80mA
Lock Output Load:  <2A
Working Temperature:  -20C – +60C
Working Humidity:  0% – 85%
Pin Capacity:  150 Custom, 150 Dynamic
Card Types:  13.56MHz Mifare Card, M1 Card
Card Capacity:  1000
Unlocking Methods:  BLE, WiFi (via Gateway sold seperately), Mifare Card
IP Rating: IP66

The MILTON Digital Keypad from Lion Head Locks is a robust, standalone keypad with integrated TTLock technology.

The MILTON offers multiple access options, including via the TTLock APP, Bluetooth, PIN code and RFID Fob/Card, as well as remote access by the Lion Head Locks optional gateway.

The MILTON can be used with electric strikes, magnetic latches and motorized gates. Featuring an IP66 rating, it is suitable for internal and external applications.

Material:  Aluminium frame/tempered glass panel
Colour:  Silver/Black
IP Rating: IP66
Dimensions: 125mm (H) x 79mm (W) x 15.5mm (D)
Unlocking Methods: APP, PIN code, Card
User Capacity:  300 PIN code (150 custom, 150 dynamic), 20,000 Card
Communication: Bluetooth 4.1
Stand-by current:  ≈5mA
Operating current:  12V

Introducing the LHL-CABLOCK – a versatile and secure cabinet lock powered by TT Lock technology. Designed for residential and commercial use, this smart lock provides advanced access control for cabinets, ensuring your valuables, supplies, or documents are safe and easily accessible.

With unlocking options including Bluetooth, PIN code, fingerprint and RFID card, the LHL-CABLOCK offers flexibility and convenience while eliminating the hassle of traditional keys. Its sturdy construction and simple installation make it an ideal choice for modern security needs.

Easily manage access permissions, track activity, and enjoy remote control through the TT Lock app. The LHL-CABLOCK combines cutting-edge technology with user-friendly features, setting a new standard for cabinet security.

Bluetooth standard:  Bluetooth 5.0 BLE
Supported mobile phone system:  Android 4.3 / IOS7.0 Up power supply mode 4 X AA Batteries
Low electric alarm voltage:  4.8V
Voltage range:  4.5~9V
Standby current: 87 Micro Ann
Working current:  Less than 200 mA
uncaging time:  Admin to 1.5 seconds
operating temperature range:  -20~70 degrees C
Key type:  Capacitive touch button
Number of passwords:  Custom and permanent password 250, Other dynamic passwords unrestricted; unbridled; unlimited;
Supported card types:  The MIFARE M1 card is available
Number of IC cards:  1000 Zhang
Unlock Methods:  App, Password, fingerprint, IC card, remote control
Fingerprint capacity:  100 Numbers

Introducing the LHL-CABINET – a smart, compact, and secure cabinet lock powered by TT Lock technology. Designed for modern convenience, this lock provides seamless access and management for cabinets in homes, offices, or commercial settings.

With multiple unlocking options, including Bluetooth,  RFID card, manual key the LHL-CABINET ensures quick and secure access while eliminating the need for traditional keys. Its robust design and easy installation make it an ideal solution for keeping valuables, documents, or supplies safe.

Manage access remotely through the TT Lock app, granting or revoking permissions and monitoring access history with ease. The LHL-CABINET is the perfect blend of functionality and smart technology, ensuring your cabinets are as secure as they are convenient.

Power supply: 4pcs 7# Alkaline batteries

Low electric alarm voltage: 4.8V

Voltage range: 4.5~9V

Voltage range: 65 μA

Working current: < 200 mA

Unlock time: ≈1.5 seconds

Working temperature Range: -20~70℃

Supported card types: MIFARE M1 card

IC cards capacity: 200pcs

Unlocking method: App, IC card

Motor interface output voltage: Battery voltage minus 0.3V

The Lion Head Locks TOORAK is a smart digital keysafe. It is ideal for house keys, car keys, fobs, etc. The TOORAK can be fixed to a wall, a door, or other solid structure. It can also be used like a padlock using the shackle that comes with the unit. This allows it to be used on gates and fences, and anywhere you can secure the shackle.

The TOORAK offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a track style override key.

The TOORAK is rated IP55, so it is best suited for applications where there is some protection from the elements.

The TOORAK is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
Colour: Black
IP Rating: IP65
Dimensions: 135mm (H) x 77.5mm (W) x 45mm (D)
Dimensions (with cover): 140.5mm (H) x 82.5mm (W) x 49mm (D)
Shackle: Yes (included)
Unlocking Methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: 200 Fingerprint, 150 PIN code, 200 Card
Key Override: Yes (track style key)
Batteries: 4 x AA alkaline (not supplied)
Battery Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Working Temperature: -25C – 55℃ degrees
Working Humidity: 20% – 95% RH
Suitable For: Doors, walls, fences, door handles (with shackle) and gates (with shackle)

The Fremantle Digital Rim Lock by Lion Head Locks brings modern security to doors where tradition or structure demands a surface-mounted solution. Whether you’re securing a heritage-listed home, a rental property, or an apartment, this stylish, full-black lock installs easily without the need for complex morticing — making it ideal for timber or original doors that can’t be modified.

With six unlocking methods including fingerprint, PIN, RFID card, mobile app, and a manual key override, the Fremantle offers flexibility for every household. It connects seamlessly to the TTLock app via Bluetooth or Wi-Fi, allowing real-time control over who enters and when. Add or revoke access remotely, monitor usage logs, and enjoy peace of mind knowing your home is secure — even when you’re not there.

The Fremantle is built tough, with an aluminum alloy body and weather-resistant design suited to Australian conditions. Powered by four AA batteries with USB-C backup, it supports up to 200 fingerprints and 150 PINs, making it perfect for busy families, guests, or shared living spaces. Simple to install, effortless to manage, and designed to protect — the Fremantle is smart security, made easy.

Material:  Aluminum alloy
Colour:  Black
Panel Sizes:  200mm x 70mm x 22mm (FRONT), 168mm x 82mm x 35mm (BACK)
Unlock method:  Wifi App, Card, Pass code, Fingerprint, Wristband or key
Batteries:  4 X AA
Batteries life: 12 Months (APPROX)
Working Temperature:  -25C – 60C
Working Humidity:  0% – 95%
Door Thickness:  35mm – 60mm
User Capacity:  200 Fingerprint, 150 Password, 200 Card

2 Year Warranty

The Lion Head Locks BEAUFORT is a modern, sophisticated digital deadbolt that is ideal for residential applications.

The BEAUFORT offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The BEAUFORT is rated IP55 (outside only), so it is best suited for applications where there is some protection from the elements.

It is supplied with a 60/70mm adjustable deadbolt.

The BEAUFORT is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material:  Zinc alloy
Colour:  Silver
IP Rating:  IP55 (exterior assembly only)
Dimensions:  140mm x 60mm x 16mm (front), 155mm x 68mm x 28mm (back)
Unlocking Methods:  APP, Fingerprint, PIN code, Card, Key
User Capacity:  200 Fingerprint, 150 PIN code, 200 Card
Key Override:  Yes (track style key)
Batteries:  4 X AA alkaline (not supplied)
Battery Life:  Up to 12 months, depending on usage
USB Back Up Power:  USB-C port
Supplied Lock/Latch:  LHL 60/70mm adjustable tubular deadbolt
Other Lock/Latch Options:  Not applicable
Working Temperature:  -25C – 60C degrees
Working Humidity:  0% – 95% RH
Door Thickness:  35mm – 55mm
Suitable For:  Wooden and metal doors

The WINDSOR by McGrath Locks is a 4-in-1 digital smart lock providing keyless entry through PIN codes, RFID access cards or tags, and Bluetooth-enabled eKeys—all managed through the McGrath Locks App—with a mechanical key override for backup entry. Supplied without a latch or lock, it suits most common Australian mortice locks and McGrath tubular latches. It has a 2-hour fire rating on E-Core and Firecore doors when used with the dormakaba MS2602 mortice lock, McGrath Locks adjustable backset tubular latch or Lockwood 530 style tubular latch.

Managed via the McGrath Locks App, it offers the flexibility to add a Wi-Fi gateway for remote access. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to family and visitors.
• Passage Mode to leave your door open when required.
• Anti-peep code function prevents unauthorised people from seeing the code input.
• Incorrect attempt lockout.
• Reset button can be disabled in App for additional security.
• Audit trail within the App to track who accessed your door and when.

Battery & Power

• Powered by 4 x AA Alkaline batteries (not included).
• Low battery alert (visible in App and audible at the lock).
• USB-C port for emergency power access.

Built to Last

• Glass screen for extra durability.
• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).

Installation

• Field changeable handing for flexible installation.
• Retrofittable with DDA compliant levers to comply with BCA AS1428.1 -2009 (Levers sold separately).
• Compatible with most common Australian mortice locks.
• Suits doors with thickness from 35-54mm.
• 2-hour fire rating for E-Core and Firecore doors.
• Supplied with the ATL6070 McGrath Locks 2-hour fire-rated tubular latch.

Finish & Lock Dimensions

• Available in black or satin nickel.
• Lock case dimensions: 180mm (H) x 72mm (W) x 25mm (D).

The ULTRA-SECUA by McGrath Locks is a 4-in-1 digital smart lock designed for screen doors. It provides keyless entry through PIN codes, RFID access cards or tags, and Bluetooth-enabled eKeys—all managed through the McGrath Locks App—with a mechanical key override for backup entry. Supplied with a mortice lock it can be retrofitted to most screen doors, including triple-locking models. Built with an IP66 weather rating (external side), the ULTRA-SECUA provides reliable performance in many different environments. Managed via the McGrath Locks App, it also includes a built-in security feature to prevent tampering with the inside handle through a fly screen.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to family and visitors.
• Passage Mode to leave your screen door unlocked when needed.
• Anti-peep code function prevents unauthorised people from seeing the code input.
• Incorrect attempt lockout after 5 wrong attempts.
• Reset button can be disabled in App for additional security.
• Audit trail within the App to track who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 2 x 3V Lithium ion batteries (included).
• Battery life of 3–4 years.
• Low battery alert (visible in App and audible at the lock).

Built to Last

• IP66 weather rated external side for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected.
• Durable design for enhanced security.

Installation

• Field changeable handing for flexible installation.
• Retrofittable with most screen door locks, including Whitco, Austral, Doric, and Lockwood.

Finish & Lock Dimensions

• Finished in Matt Black.
• Outside lock case dimensions: 295mm (H) x 42mm (W) x 24mm (D).

The STAFFORD by McGrath Locks is a sleek, durable 4-in-1 digital door lock ideal for homes, offices, or businesses. You can easily manage access through PIN codes, RFID access cards or tags, and Bluetooth-enabled eKeys—all controlled via the McGrath Locks App—with a mechanical key override for backup entry. Raised buttons offer a more comfortable, accurate feel when entering codes. Supplied with an adjustable tubular latch, it is also compatible with most common Australian commercial mortice locks. Its tempered glass screen and IP66-rated housing ensure durability, while the optional door sensor adds extra convenience. The STAFFORD is perfect for demanding applications and retrofitting doors with extra holes. Built with an IP66 weather rating (external side), the STAFFORD provides reliable performance in many different environments.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or remotely with built-in Wi-Fi.
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Low battery alert (via App and audible at the lock).
• 4 x AA alkaline batteries (Not included).
• 12 months battery life (based on 10 uses per day).
• USB-C port for emergency power access.

Built to Last

• IP66 weather rated external side for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected.
• Tempered Glass Screen for extra durability.
• DDA compliant lever design to satisfy BCA AS1428.1 -2009.

Installation

• Suits door thickness 35-55mm.

Finish & Lock Dimensions

• Lock case dimensions: 260 (H) x 45 (W) x 23mm (D).
• Finished in black or satin nickel.

The SJ8015 by McGrath Locks is a compact 4-in-1 digital door lock ideal for homes, offices, or businesses. It offers convenient access via PIN codes, RFID access cards or tags, and Bluetooth-enabled eKeys—all managed through the McGrath Locks App—with a mechanical key override for backup entry. Add a McGrath Wi-Fi gateway for remote control.

Supplied with a tubular latch and compatible with a mortice lock if needed. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Low battery alert (within App and audible at the lock).
• 9V battery contacts for emergency opening.
• USB-C port for emergency power access.

Built to Last

• Mechanical key override.
• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).

Installation

• Supplied with tubular latch; compatible with mortice lock.
• Suits door thickness 35–55mm.

Finish & Lock Dimensions

• Lock case dimensions: 154 (H) x 68mm (W).
• Lever handle projection: 78mm.
• Finished in black or silver.

The Lion Head Locks PIPER is a stylish digital door handle for internal residential applications.

The PIPER offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The PIPER is rated IP55 (outside only), making it suitable for areas with minimal exposure to the elements, however, it is best used on internal residential applications, including home offices.

The lock is not supplied with either a latch or lock body, however, it works best with the Lion Head Locks heavy duty, 60mm/70mm adjustable tubular latch.

The PIPER is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material:  Aluminium alloy
Color:  Black
IP Rating:  IP55 (exterior assembly only)
Dimensions:  165mm x 65mm
Unlocking Methods:  APP, Fingerprint, PIN code, Card, Key
User Capacity:  200 Fingerprint, 150 PIN code, 200 Card
Key Override:  Yes (track style key)
Batteries:  4 x AAA alkaline (not supplied)
Battery Life:  Up to 12 months, depending on usage
USB Back Up Power:  USB-C port
Supplied Lock/Latch:  Not supplied
Lock/Latch Options:  LHL heavy duty 60mm/70mm adjustable tubular latch
Working Temperature:  -25C – 60C degrees
Working Humidity:  0% – 95% RH
Door Thickness:  35mm – 50mm
Suitable For:  Wooden and metal internal doors

The NX5 by McGrath Locks is a stylish and feature-rich digital door lock, perfect for homes, offices, or businesses. This 5-in-1 lock offers convenient access management through the McGrath Locks App, allowing you to control lock settings, add users, and manage access via PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. The lock’s larger body size makes it ideal for retrofitting older locks, covering any extra holes left on your door. With the optional McGrath Locks Wi-Fi gateway, you can also remotely unlock and manage the NX5 from anywhere through the McGrath Locks App. Available with an adjustable tubular latch, 60mm backset tubular latch, or European mortice lock, the NX5 is a versatile and secure solution for any entryway. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Low battery alert (within App and audible at the lock).
• Powered by 4 x AA Alkaline Batteries (not included).
• USB-C port for emergency power access.

Built to Last

• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).
• Suitable for retrofitting, with a larger lock body to cover extra holes from previous installations.
• Field changeable handing for installation flexibility.
• USB-C port for emergency power access.

Installation

• Suits door thicknesses of 38-54mm.
• Comes with either an adjustable tubular latch, 60mm backset tubular latch, or European mortice lock version.
• Mechanical key override option.

Finish & Lock Dimensions

• Finished in Black or Silver for a modern, professional look.
• Lock case dimensions: 255 (H) x 65 (W) x 21mm (D).

The LHL Stronga Oval Cylinder is a premium electronic lock designed for superior security and seamless access management. Supporting PIN code, Bluetooth, fingerprint, RFID card, and mobile app (TTLock), it offers flexible entry options to suit various applications.

✔ High Capacity: Stores up to 1,000 users, 250 passwords, and 100 fingerprints
✔ Rugged Durability: IP66-rated, making it dustproof and water-resistant
✔ Long-Lasting Power: Runs on 2 x CR2 batteries, providing up to 12,000 cycles (~1 year)
✔ Emergency Access: USB-C power backup ensures reliability
✔ Temperature Resilient: Functions efficiently in extreme conditions (-25°C to 65°C)
✔ Low Battery Alert: Stay informed before power depletion

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Pincode, Fingerprint, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: Yes
Working Temperature: -25~65 degree

The Lionhead Locks G5 WIFI GATEWAY supports both 2.4GHz and 5GHz Wi-fi Connections allowing you to connect to your devices to a wi-fi network. You can then control your lock or device via the TTLock APP.

The 5GHz Wi-Fi is a faster, less congested wireless frequency allowing for a more Stable Connection.

The gateway is required to be within 8 to 10 meters of the lock (this depends on the environment), and one gateway can hold up to 100 locks or devices.

The use of a gateway allows you to remotely connect to your smart device. It is a great option for managing locks for short term rental properties, shorty stay accommodation and Airbnb properties.

Material: ABS Plastic
Colour: White
Dimensions: 70mm (H) x 70mm (W) x 26mm (D)
Connectivity: Wi-Fi 2.4GHz and 5GHz
IEEE Standard: 802.11b/g/n
Power Interface: Type-C USB
Power Input: 5V / 500mA
Power interface: Type-C USB
Range: 8 – 10 Meters (Depending on Environment)
Capacity: Up to 100 devices

The Lion Head Locks POE GATEWAY allows you to connect to your devices to an ethernet network. You can then control your lock or device via the TTLock APP.

The gateway is required to be within 10 to 15 metres of the lock (this depends on the environment), and one gateway can hold up to 100 locks or devices.

The use of a gateway allows you to remotely connect to your smart device. It is a great option for managing locks for short term rental properties, shorty stay accommodation and Airbnb properties.

The Lion Head Locks WIFI GATEWAY allows you to connect to your devices to a wi-fi network. You can then control your lock or device via the TTLock APP.

The gateway is required to be within 10 to 15 metres of the lock (this depends on the environment), and one gateway can hold up to 100 locks or devices.

The use of a gateway allows you to remotely connect to your smart device. It is a great option for managing locks for short term rental properties, shorty stay accommodation and Airbnb properties.

The STRONGA Keypad (LHL-STRONGA-KP) is a durable, IP65-rated standalone digital keypad designed to enhance and extend the functionality of compatible TTLock smart locks by providing additional unlocking methods such as fingerprint, passcode, IC card, and app control. Compact and built from ABS material, it operates reliably in harsh environments with wide temperature and humidity tolerance, making it suitable for both indoor and outdoor installations. Powered by four AAA batteries with USB-C emergency input, it can simultaneously link to up to three different smart locks, with an indicator light to show which lock is being controlled—offering a flexible, secure, and user-friendly access solution.

Product Specifications

Material: ABS

Colour: Black

Lock Size: 132mm x 43mm x 25mm

Unlock method: Fingerprint, App(TTLock), Passcode, IC card

Battery Type: 4x AAA

IP Rating: IP65

The EURO Cylinder Digital Keypad by Lion Head Locks is a durable, IP66-rated smart locking solution designed for secure and flexible access control, combining robust brass/alloy construction with modern digital features. It supports multiple unlocking methods—including PIN codes, RFID cards, mobile app control, Bluetooth, and a manual key—making it versatile for residential or commercial use. The lock accommodates up to 100 card users and 1000 app users, operates in extreme temperatures from -25°C to 65°C, and fits door thicknesses between 35mm and 100mm. Powered by a long-lasting CR123A battery (up to 18 months) with USB-C emergency power, this model offers extended size adjustability and low-battery alerts, ensuring reliability and ease of use in various environments.

Material:  Brass, Alloy, ABS
Colour:  Silver
Lock Size:  32.5mm x 32.5mm
Unlock method:  PIN, RFID Card, App, Bluetooth
Batteries Type:  CR123AX1 pcs
Batteries Life:  Up to 18 months

The EURO Cylinder Digital Keypad by Lion Head Locks is a durable, IP66-rated smart locking solution designed for secure and flexible access control, combining robust brass/alloy construction with modern digital features. It supports multiple unlocking methods—including PIN codes, RFID cards, mobile app control, Bluetooth, and a manual key—making it versatile for residential or commercial use. The lock accommodates up to 100 card users and 1000 app users, operates in extreme temperatures from -25°C to 65°C, and fits door thicknesses between 35mm and 100mm. Powered by a long-lasting CR123A battery (up to 18 months) with USB-C emergency power, this model offers extended size adjustability and low-battery alerts, ensuring reliability and ease of use in various environments.

Material: Brass, Alloy, ABS
Colour: Black
Lock Size: 32.5mm x 32.5mm
Unlock method: PIN, RFID Card, App, Bluetooth
Batteries Type: CR123AX1 pcs
Batteries Life: Up to 18 months

The Lion Head Locks EURO Cylinder Digital Keypad is a durable IP66-rated smart lock designed for both residential and commercial doors, offering five unlocking methods including fingerprint, PIN code, RFID card, manual key, and Bluetooth app control. Made from brass, alloy, and ABS, it features an extendable euro cylinder design, supports door thicknesses from 35–100 mm, and operates reliably in temperatures from -25°C to 65°C. With capacity for up to 100 fingerprints, 250 PIN codes, 100 cards, and 1000 app users, it runs on a long-lasting CR123A battery (up to 18 months) with USB-C emergency power, and includes low-battery alerts for added security and convenience.

Material: Brass, Alloy, ABS
Colour: Black
Lock Size: 32.5mm x 32.5mm
Unlock method: Fingerprint, PIN, RFID Card, Key, App, Bluetooth
Batteries Type: CR123AX1 pcs
Batteries Life: Up to 18 months

The Lion Head Locks EURO Cylinder Digital Keypad is a durable IP66-rated smart lock designed for both residential and commercial doors, offering five unlocking methods including fingerprint, PIN code, RFID card, manual key, and Bluetooth app control. Made from brass, alloy, and ABS, it features an extendable euro cylinder design, supports door thicknesses from 35–100 mm, and operates reliably in temperatures from -25°C to 65°C. With capacity for up to 100 fingerprints, 250 PIN codes, 100 cards, and 1000 app users, it runs on a long-lasting CR123A battery (up to 18 months) with USB-C emergency power, and includes low-battery alerts for added security and convenience.

Material:  Brass, Alloy, ABS
Colour:  Silver
Lock Size:  32.5mm x 32.5mm
Unlock method:  Fingerprint, PIN, RFID Card, Key, App, Bluetooth
Batteries Type:  CR123AX1 pcs
Batteries Life:  Up to 18 months

The LHL Stronga Oval Cylinder is a premium electronic lock designed for superior security and seamless access management. Supporting  Bluetooth, RFID card, and mobile app (TTLock), it offers flexible entry options to suit various applications.

✔ High Capacity: Stores up to 1,000 users
✔ Rugged Durability: IP65-rated, making it dustproof and water-resistant
✔ Long-Lasting Power: Runs on 2 x CR2 batteries, providing up to 12,000 cycles (~1 year)
✔ Temperature Resilient: Functions efficiently in extreme conditions (-25°C to 65°C)
✔ Low Battery Alert: Stay informed before power depletion

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: No
Working Temperature: -25~65 degree

The LHL Stronga Camlock is a high-performance electronic cam lock designed for versatile and secure access control. Featuring multiple unlocking methods— Bluetooth, fingerprint, RFID card, and mobile app (TTLock)—this lock ensures maximum convenience without compromising security.

Key features include:

✔ User Capacity: Supports up to 1,000 users
✔ Durable Design: IP65-rated for dust and water resistance, ideal for tough environments
✔ Long Battery Life: Powered by 2 x CR2 batteries, delivering up to 12,000 cycles (approx. 1 year)
✔ Temperature Resistant: Operates reliably in extreme conditions (-25°C to 65°C)
✔ Low Battery Alert: Stay notified before power runs out

Backed by a 2-year warranty, the Stronga Camlock is the ultimate security solution for cabinets, lockers, and enclosures.

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: No
Working Temperature: -25~65 degree

The LHL Stronga Camlock is a high-performance electronic cam lock designed for versatile and secure access control. Featuring multiple unlocking methods— PIN code, Bluetooth, fingerprint, RFID card, and mobile app (TTLock)—this lock ensures maximum convenience without compromising security.

Key features include:

✔ User Capacity: Supports up to 1,000 users, 250 passwords, and 100 fingerprints
✔ Durable Design: IP66-rated for dust and water resistance, ideal for tough environments
✔ Long Battery Life: Powered by 2 x CR2 batteries, delivering up to 12,000 cycles (approx. 1 year)
✔ Emergency Power Option: USB-C backup ensures uninterrupted access
✔ Temperature Resistant: Operates reliably in extreme conditions (-25°C to 65°C)
✔ Low Battery Alert: Stay notified before power runs out

Backed by a 2-year warranty, the Stronga Camlock is the ultimate security solution for cabinets, lockers, and enclosures

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Pincode, Fingerprint, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: Yes
Working Temperature: -25~65 degree

The LHL Stronga Rim Cylinder is a high-tech, electronic lock designed for maximum security and flexible access control. Featuring multiple unlocking options—Bluetooth,  RFID card, and mobile app (TTLock)—it provides seamless and secure access for homes and businesses.

✔ High User Capacity: Supports up to 1,000 users
✔ Rugged & Weatherproof: IP68-rated, making it dustproof and water-resistant
✔ Extended Battery Life: Powered by 2 x CR2 batteries, delivering up to 12,000 cycles (~1 year)
✔ Reliable in Any Climate: Functions effectively in extreme temperatures (-25°C to 65°C)
✔ Low Battery Alert: Get notified before power runs out

Ideal for residential, commercial, and industrial applications, the Stronga Rim Cylinder is the perfect combination of security, convenience, and cutting-edge technology.

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: No
Working Temperature: -25~65 degree

The LHL Stronga Rim Cylinder is a high-tech, electronic lock designed for maximum security and flexible access control. Featuring multiple unlocking options—PIN code, Bluetooth, fingerprint, RFID card, and mobile app (TTLock)—it provides seamless and secure access for homes and businesses.

Key Features:

✔ High User Capacity: Supports up to 1,000 users, 250 passwords, and 100 fingerprints
✔ Rugged & Weatherproof: IP66-rated, making it dustproof and water-resistant
✔ Extended Battery Life: Powered by 2 x CR2 batteries, delivering up to 12,000 cycles (~1 year)
✔ Emergency Power Backup: USB-C input ensures uninterrupted operation
✔ Reliable in Any Climate: Functions effectively in extreme temperatures (-25°C to 65°C)
✔ Low Battery Alert: Get notified before power runs out

Ideal for residential, commercial, and industrial applications, the Stronga Rim Cylinder is the perfect combination of security, convenience, and cutting-edge technology.

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Pincode, Fingerprint, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: Yes
Working Temperature: -25~65 degree

The LHL Stronga Digital Padlock is a cutting-edge, high-security lock designed for versatile and convenient access control. With multiple unlocking methods— Bluetooth, RFID card, and mobile app (TTLock)—it provides maximum flexibility for users.

✔ High User Capacity: Stores up to 1,000 users
✔ Rugged & Weatherproof: IP67-rated, ensuring dust and water resistance for outdoor and industrial use
✔ Long-Lasting Power: Runs on 2 x CR2 batteries, delivering up to 12,000 cycles (~1 year of use)
✔ Wide Temperature Range: Performs reliably in extreme conditions (-25°C to 65°C)
✔ Low Battery Alert: Stay notified before battery depletion

Perfect for gates, lockers, storage units, and commercial applications, the Stronga Digital Padlock delivers top-tier security and convenience in a sleek, modern design.

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: No
Working Temperature: -25~65 degree

The LHL Stronga Digital Padlock is a cutting-edge, high-security lock designed for versatile and convenient access control. With multiple unlocking methods—PIN code, Bluetooth, fingerprint, RFID card, and mobile app (TTLock)—it provides maximum flexibility for users.

✔ High User Capacity: Stores up to 1,000 users, 250 passwords, and 100 fingerprints
✔ Rugged & Weatherproof: IP66-rated, ensuring dust and water resistance for outdoor and industrial use
✔ Long-Lasting Power: Runs on 2 x CR2 batteries, delivering up to 12,000 cycles (~1 year of use)
✔ Emergency Access: USB-C backup power for uninterrupted operation
✔ Wide Temperature Range: Performs reliably in extreme conditions (-25°C to 65°C)
✔ Low Battery Alert: Stay notified before battery depletion

Perfect for gates, lockers, storage units, and commercial applications, the Stronga Digital Padlock delivers top-tier security and convenience in a sleek, modern design.

Material: Zinc alloy
Color: Silver/Black
Unlock Methods: APP, RFID, Pincode, Fingerprint, Bluetooth
Power Supply: 2 X CR2 Batteries
USB Back Up Power: Yes
Working Temperature: -25~65 degree

A smart lock for gates!

The COTTESLOE from Lion Head Locks is a digital lock made for wooden and metal gates.

The COTTESLOE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual key in an emergency.

The COTTESLOE is rated IP65, so it is designed to withstand Australia’s weather conditions while maintaining a refined, architectural finish.

The lock is supplied with the LHL-HD-ADJ-TUB LATCH 60/70mm adjustable tubular latch, and it will also work with all Lion Head Locks fixed tubular latches. It is available in both single keypad and dual keypad versions.

The COTTESLOE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy
Colour: Black
IP Rating: IP65
Dimensions: 180mm x 45mm x 30mm
Unlocking methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: A200 Fingerprint, 150 Pin code, 200 Card
Key Override: Yes (5 pin key, LW4 profile)
Batteries: 2 X CR123
Batteries life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Supplied Lock/Latch: LHL-,HD-ADJ-TUB-LATCH (round edge face plate)
Other Lock/Latch Options: LHL fixed tubular latches
Working Temperature: -25C – 60C degrees
Working Humidity: 0% – 95% RH
Door Thickness: 35mm – 50mm
Suitable For: Wooden and metal gates

A smart lock for gates!

The COTTESLOE from Lion Head Locks is a digital lock made for wooden and metal gates.

The COTTESLOE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual key in an emergency.

The COTTESLOE is rated IP65, so it is designed to withstand Australia’s weather conditions while maintaining a refined, architectural finish.

The lock is supplied with the LHL-HD-ADJ-TUB LATCH 60/70mm adjustable tubular latch, and it will also work with all Lion Head Locks fixed tubular latches. It is available in both single keypad and dual keypad versions.

The Lion Head Locks LYGON is a sleek, slimline digital door lock, available with either a lever handle or hexagonal knob.

The LYGON offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The LYGON is rated IP55 (outside only). It is ideal for most applications, other than those at are fully exposed to the elements. The LYGON can be used on both hinged and sliding doors, subject to the type of mortice lock used.

The lock is not supplied with a lock body, however, the LYGON will operate with all LHL 85 series swing bolt and hook mortice locks.

The LYGON is not recommended for use with a tubular latch.

The LYGON is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
Colour: Black
IP Rating: IP55 (exterior assembly only)
Dimensions: 316mm x 31mm x 22mm
Unlocking Methods: APP, Fingerprint, PIN code, Card, Key
Key Override: Yes (track style key)
Batteries: 4 x AAA alkaline (not supplied)
Battery Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Supplied Lock/Latch: Not supplied
Lock/Latch Options: LHL 85 series swing bolt and hook mortise locks
Working Temperature: -25 – 60C degrees
Working Humidity: 0% -95% RH
Apply Door Thickness: 35mm – 50mm
Suitable For: Wooden and metal doors

The A210 by McGrath Locks is a sleek 5-in-1 digital smart lock designed for narrow stile aluminium doors, making it ideal for homes, offices, and commercial settings. Access can be granted via PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys through the McGrath Locks App, or a mechanical key override. Lock functions are easily managed via the McGrath Locks App, with the option to add a Wi-Fi gateway for remote control and monitoring. Supplied with a European mortice lock, the A210 is also compatible with the McGrath Locks 85 series mortice lock range. Rated IP65 (external handle only), it’s built to perform in demanding environments.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AA alkaline batteries (not included).
• Low battery alerts in the app and audible at the lock.
• USB-C port for emergency power access.

Installation

• Supplied with a European mortice lock (85mm).
• Compatible with the McGrath Locks 85 series mortice lock range.
• Field changeable handing for left or right hinged doors.
• Batteries must be installed to change handing.

Built to Last

• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).

Finish & Lock Dimensions

• Finished in black or satin chrome.
• Lock case dimensions: 303 (H) x 43 (W) x 22.5mm (D).

The A210D by McGrath Locks is a slimline, double-sided digital smart lock offering all the versatility of the A210, with the added benefit of access control on both sides of the door. This 5-in-1 digital door lock is designed for narrow stile doors, making it an ideal choice for homes, offices, and businesses. Easily manage lock functions through the powerful McGrath Locks App, allowing you to control access using PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. With the optional McGrath Locks Wi-Fi gateway, you can unlock your door remotely from anywhere in the world. The A210D is supplied with a European mortice lock and features a 43mm wide body suited to most aluminium doors. Built for durability with an IP65 weather rating (on both sides), and with access on both sides, it offers enhanced convenience and security.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AA alkaline batteries (not included).
• Low battery alerts in the app and audible at the lock.
• USB-C port for emergency power access.

Installation

• Double-sided access control, providing controlled entry from both sides of the door.
• Supplied with a European mortice lock (85mm).
• Compatible with the McGrath Locks 85 series mortice lock range.
• Field changeable handing for left or right hinged doors.
• Batteries must be installed to change handing.

Built to Last

• IP65-rated for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).

Finish & Lock Dimensions

• Finished in black or satin chrome.
• Lock case dimensions: 303 (H) x 43 (W) x 22.5mm (D).

The A231 by McGrath Locks is a slimline digital smart lock with many features making it a great addition to the home, office or business. This 5 in 1 digital door lock is designed for doors with a narrow stile and provides a versatile and convenient method of entry that allows you to easily manage who has access to your property. Utilising the powerful McGrath Locks App, lock and user settings are easily configured and managed. Access can be provided to family and visitors alike through PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. By adding a McGrath Locks Wi-Fi gateway you can remotely unlock the A231 from anywhere in the world using the McGrath Locks App. The A231 can be ordered with a lever or hexagonal handle. It is supplied with a European mortice lock and has a 31 mm wide body suited to most swinging or sliding aluminium doors. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• 4 x AAA Alkaline Batteries (not included).
• Low battery alert (within App and audible at the lock).
• USB-C port for emergency power access.
• USB-C port for emergency power access.

Built to Last

• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).
• Made from durable materials to withstand wear and tear.

Installation

• Supplied with a European mortice lock.
• Compatible with the McGrath Locks 85 series mortice lock range.
• Suits doors with thickness 28-55mm.
• Field changeable left and right door handing.

Finish & Lock Dimensions

• Lock case dimensions: 316 (H) x 31 (W) x 19.7mm (D).
• Finished in black or silver.

The A231HEX by McGrath Locks is a slimline digital smart lock with a variety of features, making it perfect for homes, offices, or businesses. This 5-in-1 digital smart lock is designed for narrow stile doors, offering a versatile and convenient entry solution. It allows you to easily manage access for family and visitors. Utilising the McGrath Locks App, lock and user settings are easily configured and managed. Access can be provided via PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. With the McGrath Locks Wi-Fi gateway, you can unlock the A231HEX remotely from anywhere using the app. It has a 31 mm wide body, making it compatible with most swinging or sliding aluminium doors. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AAA Alkaline batteries (not included).
• Low battery alert within the App and audible at the lock.

Built to Last

• Made from durable materials for long-lasting use.
• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).
• Temperature resistant from -20°C to 60°C for all-weather reliability.
• Humidity tolerance from 10% to 98% for reliable operation in varying conditions.

Installation

• Supplied with a European mortice lock.
• Compatible with the McGrath Locks 85 series mortice lock range.
• Field changeable left and right door handing.
• Suits door thickness 28-55mm.

Finish & Lock Dimensions

• Finished in black or silver.
• Lock case dimensions: 316 (H) x 31 (W) x 19.7mm (D).

The A231HEX-S by McGrath Locks is a slimline digital smart lock designed for sliding doors with the hex shaped handle allowing your sliding doors to open fully. Featuring 5-in-1 access methods, the A231HEX-S is a great addition to homes, offices, or businesses. It is ideal for narrow stile doors and provides a versatile and convenient method of entry, allowing you to easily manage who has access to your property. Utilising the powerful McGrath Locks App, lock and user settings are easily configured and managed. Access can be provided to family and visitors alike through PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. By adding a McGrath Locks Wi-Fi gateway, you can remotely unlock the A231HEX-S from anywhere in the world using the McGrath Locks App. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AAA Alkaline batteries (not included).
• Low battery alert within the App and audible at the lock.
• USB-C port for emergency power access.

Built to Last

• Made from durable materials for long-lasting use.
• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).
• Temperature resistant from -20°C to 60°C for all-weather reliability.
• Humidity tolerance from 10% to 98% for reliable operation in varying conditions.

Installation

• Comes with a hook bolt lock mechanism, ideal for sliding doors.
• Compatible with the McGrath Locks 85 series mortice lock range (for non-sliding doors).
• Field changeable left and right door handing.
• Suits door thickness 28-55mm.

Finish & Lock Dimensions

• Finished in black or silver.
• Lock case dimensions: 316 (H) x 31 (W) x 19.7mm (D).

The A236 by McGrath Locks is a stylish, slimline digital smart lock designed for both residential and commercial applications. This 5-in-1 digital door lock is perfect for doors with a narrow stile and offers a versatile and convenient method of entry, allowing you to manage access easily. With the powerful McGrath Locks App, lock and user settings are easily configured and managed. Access can be granted through PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. You can also add a McGrath Locks Wi-Fi gateway for remote access, enabling you to unlock the A236 from anywhere using the McGrath Locks App. The A236 is supplied with a European mortice lock featuring a 35 mm backset, and its 36 mm wide body is suited to most aluminium doors, ensuring a seamless fit. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AAA Alkaline batteries (not included).
• Low battery alert within the App and audible at the lock.
• USB-C port for emergency power access.

Built to Last

• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).
• Temperature resistant from -20°C to 60°C for reliable all-weather operation.
• Humidity tolerance from 10% to 98%, ensuring reliable performance in varying conditions.

Installation

• Supplied with a European mortice lock.
• Compatible with the McGrath Locks 85 series mortice lock range.
• Field changeable left and right door handing for flexibility during installation.
• Suits door thicknesses of 35-55mm.

Finish & Lock Dimensions

• Finished in black or silver.
• Lock case dimensions: 350 (H) x 36mm (W).

The ALBION by McGrath Locks is a 4-in-1 digital smart lock offering keyless entry through the powerful McGrath Locks App, allowing you to control access using PIN codes, RFID access cards or tags, Bluetooth-enabled eKeys through the McGrath Locks App, or a mechanical key override. It’s supplied with an adjustable tubular latch or European mortice lock version and is compatible with most common Australian commercial mortice locks. The ALBION also supports remote access with the optional Wi-Fi gateway. Available in black or satin nickel, it provides both security and convenience for any property. Built for durability with an IP65 weather rating (external handle only), it provides reliable access control for various applications.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AA Alkaline batteries (not included).
• Low battery alert (visible in App and audible at the lock).
• USB-C emergency opening for backup access.

Built to Last

• Durable glass screen for extra protection.
• IP65-rated external side for dust and light water resistance — designed for sheltered or undercover areas (not suitable for direct rain exposure).

Installation

• Field changeable handing for flexible installation.
• Compatible with most common Australian mortice locks.
• Adjustable door thickness – fits doors from 35mm to 54mm.
• Supplied with adjustable tubular latch or European mortice lock version.

Finish & Lock Dimensions

• Finished in black or satin nickel.
• Lock case dimensions: 180mm (H) x 72mm (W) x 25mm (D)

The ASCOT by McGrath Locks is a 4-in-1 digital smart lock designed for residential and light commercial applications, including gates with the added benefit of access control on both sides. Access is granted via the powerful McGrath Locks App, allowing you to control entry using PIN codes, RFID access cards or tags, Bluetooth-enabled eKeys through the McGrath Locks App, or a mechanical key override. It is supplied with a tubular latch. The ASCOT is easy to manage via the McGrath Locks App and offers optional remote access with the Wi-Fi gateway. Built with an IP66 weather rating, the ASCOT provides reliable performance in many different environmentsAvailable in black, polished chrome, or satin chrome, it’s a versatile choice for your property.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AAA Alkaline batteries per handle (not included).
• Low battery alert (visible in App and audible at the lock).
• USB-C port for emergency power access.

Built to Last

• IP66-rated on both sides for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected.
• Tempered glass screen for extra durability.

Installation

• Field changeable handing for flexible installation.
• Supplied with adjustable tubular latch.

Finish & Lock Dimensions

• Available in Black, Polished Chrome, or Satin Chrome finishes.
• Lock rose dimensions: 75mm

2 Year Warranty

The Lion Head Locks ASPEN VH (VERTICAL HANDLE) is a modern, sleek digital door lock. The compact vertical handle allows the lock to be used in applications where there is not enough room for a traditional lever handle. The ASPEN offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency. The ASPEN is rated IP66 (exterior only). If the lock is fully exposed to the elements, the interior assembly needs to be protected from moisture. The lock is supplied with the LHL-SW-MORTICE-30 mortice lock (85 series), with 30mm backset and 85mm pitch. It will also work with all Lion Head Locks 85 series mortice locks. The ASPEN is simple to use and is easy to program, using the TTLock APP.The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP66 (exterior assembly only)

Dimensions: 284mm x 34mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AAA alkaline (not supplied)

Battery Life: up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: LHL-SW-MORTICE-30

Other Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95%

Door Thickness 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks ASPEN is a modern, sleek digital door lock.

The ASPEN offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ASPEN is rated IP66 (exterior only). If the lock is fully exposed to the elements, the interior assembly needs to be protected from moisture.

The lock is supplied with the LHL-SW-MORTICE-35 mortice lock (85 series), with 35mm backset and 85mm pitch. It will also work with all Lion Head Locks 85 series mortice locks.

The ASPEN is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP66 (exterior assembly only)

Dimensions: 284mm x 34mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AAA alkaline (not supplied)

Battery Life: up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: LHL-SW-MORTICE-35

Other Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95%

Door Thickness 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks ASPEN is a modern, sleek digital door lock.

The ASPEN offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ASPEN is rated IP66 (exterior only). If the lock is fully exposed to the elements, the interior assembly needs to be protected from moisture.

The lock is supplied with the LHL-SW-MORTICE-35 mortice lock (85 series), with 35mm backset and 85mm pitch. It will also work with all Lion Head Locks 85 series mortice locks.

The ASPEN is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy

Colour: Silver/Black

IP Rating: IP66 (exterior assembly only)

Colour: Silver/Black

Dimensions: 284mm x 34mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track key override)

Batteries: 4 X AAA alkaline (not supplied)

Battery life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: LHL-SW-MORTICE-35

Other Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95%

Door Thickness 35mm – 65mm

Suitable For: Wooden and metal doors

The BARDON by McGrath Locks is a versatile 4-in-1 digital smart lock designed for both residential and commercial use. With multiple access options—PIN codes, RFID access cards or tags, Bluetooth-enabled eKeys via the McGrath Locks App, and a mechanical key override, it offers flexible and secure entry management. Raised buttons offer a more comfortable, accurate feel when entering codes. Its DDA-compliant lever makes entry effortless for everyone, while the tempered glass screen ensures durability. The BARDON is designed to be installed with ANSI mortice locks but can be also installed with a European mortice lock and tubular latch (no key override). Built with an IP66 weather rating, the BARDON provides reliable performance in many different environments, making it an ideal choice for high-traffic areas.

SKU: BARDON-INTL

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or remotely with built-in Wi-Fi
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to your family and visitors.
• Raised buttons offer a more comfortable, accurate feel when entering codes.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Low battery alert (within App and audible at the lock).
• Powered by 4 x AA alkaline batteries (not included).
• 12 months battery life (Based on 10 uses per day).
• USB-C port for emergency power access.

Built to Last

• Tempered glass screen for extra durability.
• IP66 weather rated external side for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected.

Installation

• Suits door thickness 35-55mm.
• Compatible with tubular latch, ANSI, and European mortice lock systems.
• DDA-compliant lever design to satisfy BCA AS1428.1 -2009.

Finish & Lock Dimensions

• Finished in matt black or nickel silver for a modern, professional look.
• Lock case dimensions: 270 (H) x 65 (W) x 25mm (D).

The Lion Head Locks BONDI is a stylish, commercial grade digital door lock, with a DDA compliant lever handle, and an IP55 Rating (outside only).

The BONDI offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. The BONDI can also be opened by a traditional key if the optional oval cylinder is fitted.

The BONDI is designed to work with the LHL-MF-MORTICE multi function mortice lock, however, it will also work with the LHL-OZ-MORTICE, and other mortice locks with an 8mm spindle hub.

The BONDI is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy

Colour: Silver/Black

IP Rating: IP55 (exterior assembly only)

Dimensions:300mm x 60mm x 18mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Oval cylinder required for key override (not supplied)

Batteries: 4 X AAA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Recommended Lock/Latch: LHL-MF-MORTICE

Other Lock/Latch Options: LHL-OZ-MORTICE, dormakaba 2602 mortice lock

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95%

Door Thickness 35mm – 65mm

Suitable For: Wooden and timber doors

The Lion Head Locks CARLISLE is a compact digital door lock.

The CARLISLE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The CARLISLE is rated IP55 (outside only) meaning it offers reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is supplied with the LHL-HD-ADJ-TUB LATCH 60/70mm adjustable tubular latch, and it will also work with all Lion Head Locks fixed tubular latches.

The CARLISLE is the perfect and simple upgrade option for an existing knob set or lever set.

The CARLISLE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
Colour: Silver
IP Rating: IP55 (exterior assembly only)
Dimensions: 135mm x 73mm x 22mm
Unlocking Methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: 200 Fingerprint, 150 PIN code, 200 Card
Key Override: Yes (5 pin traditional key, LW4/C4 keyway)
Batteries: 4 X AA alkaline (not supplied)
Batteries Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Recommended Lock/Latch: LHL-HD-ADJ-TUB-LATCH (supplied)
Other Lock/Latch Options: LHL fixed tubular latches
Working Temperature: -25C – 60C degrees
Working Humidity: 0% – 95% RH
Door Thickness: 35mm – 65mm
Suitable For: Wooden and metal doors

The Lion Head Locks CARLISLE is a compact digital door lock.

The CARLISLE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The CARLISLE is rated IP55 (outside only) meaning it offers reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is supplied with the LHL-HD-ADJ-TUB LATCH 60/70mm adjustable tubular latch, and it will also work with all Lion Head Locks fixed tubular latches.

The CARLISLE is the perfect and simple upgrade option for an existing knob set or lever set.

The CARLISLE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Silver

IP Rating: IP55 (exterior assembly only)

Dimensions: 135mm x 73mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (5 pin traditional key, LW4/C4 keyway)

Batteries: 4 X AA alkaline (not supplied)

Batteries Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Recommended Lock/Latch: LHL-HD-ADJ-TUB-LATCH (supplied)

Other Lock/Latch Options: LHL fixed tubular latches

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks COLLINS is a stylish mid-sized digital door lock.

The COLLINS offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The COLLINS is rated IP55 (outside only), offering reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is not supplied with either a latch or a lock body, however, the COLLINS is a very versatile lock and it will operate with all LHL tubular latches and all LHL 5050 series & 6050 series mortice locks. The use of a mortice lock with the COLLINS provides an additional level of security.

When installed with a tubular latch, the COLLINS is great for replacing an existing knob set or lever set without the need to make major modifications.

The COLLINS is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
Colour: Black
IP Rating: IP55 (exterior assembly only)
Dimensions: 225mm x 65mm x 22mm
Unlocking Methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: 200 Fingerprint, 150 PIN code, 200 Card
Key Override: Yes (track style key)
Batteries: 4 x AA alkaline (not supplied)
Battery Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Recommended Lock/Latch: LHL-HD-ADJ-TUB-LATCH
Other Lock/Latch Options: LHL fixed tubular latches, LHL 5050 & 6050 mortice locks
Working Temperature: -25C – 60C degrees
Working Humidity: 0% – 95% RH
Door Thickness: 35mm – 65mm
Suitable For: Wooden and metal doors

Built In Wi-Fi

The Lion Head Locks ENMORE is a sophisticated digital door lock, with built in Wi-Fi.

The ENMORE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ENMORE is rated IP55 (outside only). It is supplied with the LHL-SW-MORTICE-6068 heavy duty mortice lock, however, it will also work with Lion Head Locks tubular latches and the LHL MF and OZ mortice locks.

The ENMORE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
IP Rating: IP55 (exterior assembly only)
Colour: Black
Dimensions: 300mm X 67mm x 22mm
Unlocking methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: 200 Fingerprint, 150 PIN code, 200 Card
Track Key Override: Yes
Batteries: 4 X AA alkaline (not supplied)
Battery Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Recommended Lock/Latch: LHL-SW-MORTICE-6068 heavy duty mortice lock (supplied)
Other Lock/Latch Options: LHL fixed and adjustable tubular latches, LHL-MF-MORTICE and LHL-OZ-MORTICE
Working Temperature: -25C – 60C degrees
Working Humidity: 0% – 95%
Door Thickness: 35mm – 65mm
Suitable For: Wooden and metal doors

The Lion Head Locks ERSKINE is a stylish, slimline digital door lock.

The ERSKINE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ERSKINE is rated IP55 (outside only). It offers reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is supplied with the LHL-SW-MORTICE-35 short-backset mortice lock, and it will also work with all Lion Head Locks 85 series mortice locks and 92 series “hook” mortice locks.

The ERSKINE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
Colour: Black
IP Rating: IP55 (exterior assembly only)
Dimensions: 310mm 39mm x 23mm
Unlocking Methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: 200 Fingerprint, 150 PIN code, 200 Card
Key Override: Yes (track style key)
Batteries: 4 X AA alkaline (not supplied)
Batteries Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Recommended Latch/Lock: LHL-SW-MORTICE-35
Other Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks
Working Temperature: -25C – 60C degrees
Working Humidity: 0% – 95% RH
Door Thickness: 35mm – 65mm
Suitable For: Wooden and metal doors

The HAMILTON by McGrath Locks is one of the most versatile digital smart locks available in Australia. It is a 5-in-1 digital smart lock offering keyless entry through PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. Supplied with an adjustable tubular latch, it is also compatible with most common Australian commercial mortice locks. The lock is fire-rated for up to 2 hours plus, its DDA-compliant lever makes entry effortless for everyone. Easily managed via the McGrath Locks App, you can control access remotely with the optional Wi-Fi gateway. Built with an IP66 weather rating, the HAMILTON provides reliable performance in many different environments. Perfect for both residential and commercial properties, it combines security and convenience.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AA Alkaline batteries (not included).
• Low battery alert (visible in App and audible at the lock).
• USB-C port for emergency power access.

Built to Last

• Glass screen for extra durability.
• IP66 weather rated external side for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected.

Installation

• Field changeable handing for flexible installation.
• Retrofittable with DDA compliant levers to comply with BCA AS1428.1 -2009 (Levers sold separately).
• Compatible with most common Australian mortice locks.
• Suits doors with thickness from 35–54mm.
• 2-hour fire rating for E-Core and Firecore doors.
• Supplied with the ATL6070 McGrath Locks 2-hour fire-rated tubular latch.

Finish & Lock Dimensions

• Available in black or satin nickel.
• Lock case dimensions: 180mm (H) x 72mm (W) x 25mm (D).

The KSBK Keysafe by McGrath Locks is a stylish and feature-rich key box that can securely store a spare key or access card to your property. Ideal for homes, offices, businesses, or short-term rentals like Airbnb, it provides a versatile and convenient method of entry, allowing you to easily manage who has access. Utilising the powerful McGrath Locks App, lock and user settings are easily configured and managed. Access can be provided to family, visitors, or guests through PIN codes, RFID access cards or tags, fingerprint recognition, Bluetooth-enabled eKeys, or a mechanical key override. By adding a McGrath Locks Wi-Fi gateway, you can remotely unlock the KEYSAFE from anywhere in the world using the McGrath Locks App. The KEYSAFE has a protective cover for weather protection and can be wall or shackle mounted for flexible installation.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
• Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Powered by 4 x AAA Alkaline Batteries (not included).
• Low battery alert (within the App and audible at the lock).
• USB-C port for emergency power access.

Built to Last

• Glass Screen for extra durability.
• Protective cover for weather protection.

Installation

• Supplied with a shackle for hanging or can be wall-mounted.

Finish & Lock Dimensions

• Finished in black for a professional look.
• Case dimensions: 138 (H) x 82.5 (W) x 45mm (D).

The BARDON by McGrath Locks is a versatile 4-in-1 digital smart lock designed for both residential and commercial use. With multiple access options—PIN codes, RFID access cards or tags, Bluetooth-enabled eKeys via the McGrath Locks App, and a mechanical key override, it offers flexible and secure entry management. Raised buttons offer a more comfortable, accurate feel when entering codes. Its DDA-compliant lever makes entry effortless for everyone, while the tempered glass screen ensures durability. The BARDON is designed to be installed with ANSI mortice locks but can be also installed with a European mortice lock and tubular latch (no key override). Built with an IP66 weather rating, the BARDON provides reliable performance in many different environments, making it an ideal choice for high-traffic areas.

Lock Functions

• Manage lock functions via McGrath Locks App using Bluetooth or remotely with Wi-Fi via a gateway.
• Enrol PIN Codes, RFID access cards & tags, and send eKeys to your family and visitors.
• Raised buttons offer a more comfortable, accurate feel when entering codes.
• Passage Mode can be used to leave your door open when required.
• Anti-peep code function stops unauthorised people from seeing the correct code inputted.
• Incorrect attempt lockout after 5 wrong attempts for added security.
• Reset button can be disabled in the App for additional security.
• Audit trail within the App to see who accessed your door and when.
• Mechanical key override option for emergency access.

Battery & Power

• Low battery alert (within App and audible at the lock).
• Powered by 4 x AA alkaline batteries (not included).
• 12 months battery life (Based on 10 uses per day).
• USB-C port for emergency power access.

Built to Last

• Tempered glass screen for extra durability.
• IP66 weather rated external side for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected..

Installation

• Suits door thickness 35-55mm.
• Compatible with tubular latch, ANSI, and European mortice lock systems.
• DDA-compliant lever design to satisfy BCA AS1428.1 -2009.

Finish & Lock Dimensions

• Finished in matt black or nickel silver for a modern, professional look.
• Lock case dimensions: 270 (H) x 65 (W) x 25mm (D).

The Lion Head Locks BONDI is a stylish, commercial grade digital door lock, with a DDA compliant lever handle, and an IP55 Rating (outside only).

The BONDI offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. The BONDI can also be opened by a traditional key if the optional oval cylinder is fitted.

The BONDI is designed to work with the LHL-MF-MORTICE multi function mortice lock, however, it will also work with the LHL-OZ-MORTICE, and other mortice locks with an 8mm spindle hub.

The BONDI is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy

IP Rating: IP55

Colour: Black, Silver

Panel Sizes: 300mm x 60mm

Field Changeable: YES

Unlock method: Wifi App, Card, Pass code, Fingerprint, Wristband or key

Key Override: Oval Cylinder for Key Override

Batteries: 4 X AA

Batteries life: 12 Months

USB Power: USB-C Included

Working Temperature: -25C – 60C

Working Humidity: 0% – 95%

Door Thickness: 35mm – 65mm

User Capacity: 200 Fingerprint, 150 Password, 200 Card

The Lion Head Locks CARLISLE is a compact digital door lock.

The CARLISLE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The CARLISLE is rated IP55 (outside only) meaning it offers reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is supplied with the LHL-HD-ADJ-TUB LATCH 60/70mm adjustable tubular latch, and it will also work with all Lion Head Locks fixed tubular latches.

The CARLISLE is the perfect and simple upgrade option for an existing knob set or lever set.

The CARLISLE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy
Colour: Silver
IP Rating: IP55 (exterior assembly only)
Dimensions: 135mm x 73mm x 22mm
Unlocking Methods: APP, Fingerprint, PIN code, Card, Key
User Capacity: 200 Fingerprint, 150 PIN code, 200 Card
Key Override: Yes (5 pin traditional key, LW4/C4 keyway)
Batteries: 4 X AA alkaline (not supplied)
Batteries Life: Up to 12 months, depending on usage
USB Back Up Power: USB-C port
Recommended Lock/Latch: LHL-HD-ADJ-TUB-LATCH (supplied)
Other Lock/Latch Options: LHL fixed tubular latches
Working Temperature: -25C – 60C degrees
Working Humidity: 0% – 95% RH
Door Thickness: 35mm – 65mm
Suitable For: Wooden and metal doors

The Lion Head Locks ENMORE is a sophisticated digital door lock, with built in Wi-Fi.

The ENMORE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ENMORE is rated IP55 (outside only). It is supplied with the LHL-SW-MORTICE-6068 heavy duty mortice lock, however, it will also work with Lion Head Locks tubular latches and the LHL MF and OZ mortice locks.

The ENMORE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy

IP Rating: IP55

Colour: Black

Panel Sizes: 300mm X 67mm x 22mm

Unlock method: wifi App, Card, Pass code, Fingerprint, Wristband or key

Track Key Override: Yes

Batteries: 4 X AA

Batteries life: 12 Months

USB Power: USB-C Included

Working Temperature: -25C – 60C

Working Humidity: 0% – 95%

Door Thickness 35mm – 65mm

User Capacity 200 Fingerprint, 150 Password, 200 Card

The Lion Head Locks ERSKINE is a stylish, slimline digital door lock.

The ERSKINE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ERSKINE is rated IP55 (outside only). It offers reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is supplied with the LHL-SW-MORTICE-35 short-backset mortice lock, and it will also work with all Lion Head Locks 85 series mortice locks and 92 series “hook” mortice locks.

The ERSKINE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy

IP Rating: IP55

Colour: Black/Silver

Panel Sizes:310mm x 39mm x 23mm

Field Changeable: YES

Unlock method: WiFi App, Card, Passcode, Fingerprint, Wristband or Key

Key Override: Track Key Override

Batteries: 4 X AA

Batteries Life: 12 Months

USB Power: USB-C Included

Working Temperature: -25C – 60C

Working Humidity: 0% – 95%

Door Thickness 35mm – 65mm

User Capacity: 200 Fingerprint, 150 Password, 200 Card

The Lion Head Locks LONSDALE is modern, commercial grade digital door lock.

The LONSDALE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The LONSDALE is rated IP55 (outside only), making it suitable for areas with minimal exposure to the elements. It is not recommended for applications that are fully exposed to the elements.

The lock is supplied with the LHL-SW-MORTICE-6068 heavy duty mortice lock. It will also work with Lion Head Locks tubular latches, LHL 5050 & 6050 series mortice locks & LHL 85 series mortice locks.

The LONSDALE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 370mm x 75mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 X AA alkaline (not supplied)

Batteries Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Recommended Lock/Latch: LHL-SW-MORTICE-6068

Other Lock/Latch Options: LHL adjustable & fixed tubular latches, LHL 5050 & 6050 series mortice locks & LHL 85 series mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness: 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks ESSEX is a sleek, slimline digital door lock, suitable for outdoor conditions, including gates.

The ESSEX offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The ESSEX is rated IP66 (outside only). If the lock is fully exposed to the elements, the interior assembly needs to be protected from moisture.

The lock is not supplied with a lock body, however, the ESSEX will operate with all LHL 85 series swing bolt and hook mortice locks.

The ESSEX is not recommended for use with a tubular latch.

The ESSEX is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.If the lock is fully exposed to the elements, the interior assembly needs to be protected from moisture.

Material: Aluminium alloy

Color: Black

IP Rating: IP66 (exterior assembly only)

Dimensions: 350mm x 36mm x 24.3mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AAA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: Not supplied

Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks (not supplied)

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness: 35mm – 65mm

Suitable For: Wooden and metal doors and gates

The Lion Head Locks REGENT is a modern, sophisticated digital door lock that is perfect for residential applications.

The REGENT offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The REGENT is rated IP55, so it is best suited for applications where there is some protection from the elements.

It is supplied with the LHL-HD-ADJ-TUB-LATCH heavy duty, 60/70mm tubular latch, however, it will also work with all Lion Head Locks fixed tubular latches (60mm, 70mm & 127MM).

The REGENT is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 200mm x 70mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 X AA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: LHL-HD-ADJ-TUB-LATCH heavy duty 60/70mm adjustable tubular latch

Other Lock/Latch Options: LHL fixed tubular latches

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95%

Door Thickness: 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks OXFORD (DOUBLE) is a stylish, slimline digital door lock, suitable for most outdoor conditions. It features a keypad on outside and on the inside, allowing entry and exit to be controlled on both sides of the door.

The OXFORD (DOUBLE) offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The OXFORD (DOUBLE) is rated IP65 (outside only), making it suitable for most external applications, other than those at are fully exposed to the elements.

The lock is not supplied with a lock body, however, the OXFORD will operate with all LHL 85 series swing bolt and hook mortice locks.

The OXFORD (DOUBLE) is not recommended for use with a tubular latch.

The OXFORD (DOUBLE) is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Color: Black

IP Rating: IP65 (exterior assembly only)

Dimensions: 303mm x 43mm x 22.5mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AAA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: Not supplied

Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness: 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks FRANKLIN is a stylish, user-friendly digital deadbolt that is ideal for residential and commercial applications.

The FRANKLIN offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a traditional manual key.

The FRANKLIN is rated IP55 (outside only), so it is best suited for applications where there is some protection from the elements.

It is supplied with a 60/70mm adjustable deadbolt.

The FRANKLIN is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP55 (exterior assembly only)

Dimensions:153mm x 68mm x 29.5mm (front), 173mm x 72mm x 51.5mm (back)

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (5 pin traditional key, Schlage keyway)

Batteries: 4 X AA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: LHL 60/70mm adjustable tubular deadbolt

Other Lock/Latch Options: Not applicable

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness: 35mm – 55mm

Suitable For: Wooden and metal doors

The Lion Head Locks COLLINS is a stylish mid-sized digital door lock.

The COLLINS offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The COLLINS is rated IP55 (outside only), offering reasonable protection from dust and moisture, but it is not suitable for applications fully exposed to the weather.

The lock is not supplied with either a latch or a lock body, however, the COLLINS is a very versatile lock and it will operate with all LHL tubular latches and all LHL 5050 series & 6050 series mortice locks. The use of a mortice lock with the COLLINS provides an additional level of security.

When installed with a tubular latch, the COLLINS is great for replacing an existing knob set or lever set without the need to make major modifications.

The COLLINS is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 225mm x 65mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Recommended Lock/Latch: LHL-HD-ADJ-TUB-LATCH

Other Lock/Latch Options: LHL fixed tubular latches, LHL 5050 & 6050 mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness: 35mm – 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks LYGON is a sleek, slimline digital door lock, available with either a lever handle or hexagonal knob.

The LYGON offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The LYGON is rated IP55 (outside only). It is ideal for most applications, other than those at are fully exposed to the elements. The LYGON can be used on both hinged and sliding doors, subject to the type of mortice lock used.

The lock is not supplied with a lock body, however, the LYGON will operate with all LHL 85 series swing bolt and hook mortice locks.

The LYGON is not recommended for use with a tubular latch.

The LYGON is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 316mm x 31mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

Key Override: Yes (track style key)

Batteries: 4 x AAA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: Not supplied

Lock/Latch Options: LHL 85 series swing bolt and hook mortice locks

Working Temperature: -25 – 60C degrees

Working Humidity: 0% -95% RH

Apply Door Thickness: 35mm – 50mm

Suitable For: Wooden and metal doors

The Lion Head Locks LYGON is a sleek, slimline digital door lock, available with either a lever handle or hexagonal knob.

The LYGON offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The LYGON is rated IP55 (outside only). It is ideal for most applications, other than those at are fully exposed to the elements. The LYGON can be used on both hinged and sliding doors, subject to the type of mortice lock used.

The lock is not supplied with a lock body, however, the LYGON will operate with all LHL 85 series swing bolt and hook mortice locks.

The LYGON is not recommended for use with a tubular latch.

The LYGON is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 316mm x 31mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

Key Override: Yes (track style key)

Batteries: 4 x AAA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: Not supplied

Lock/Latch Options: LHL 85 series swing bolt and hook mortise locks

Working Temperature: -25 – 60C degrees

Working Humidity: 0% -95% RH

Apply Door Thickness: 35mm – 50mm

Suitable For: Wooden and metal doors

The Lion Head Locks NICHOLSON is digital door lock for both residential and commercial applications.

The NICHOLSON offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The NICHOLSON is rated IP55 (outside only), making it suitable for areas with minimal exposure to the elements. It is not recommended for applications that are fully exposed to the elements.

The lock is not supplied with either a latch or lock body, however, its versality allows it to be used with Lion Head Locks tubular latches, LHL 5050 & 6050 series mortice locks & LHL 85 series mortice locks. The use of a mortice lock greatly improves the security of the lock.

The NICHOLSON is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminium alloy

Colour: Silver/Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 234mm x 76mm x 25mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 X AA alkaline (not supplied)

Battery life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Supplied Lock/Latch: Lock/latch not included

Lock/Latch Options: LHL-fixed & adjustable tubular latches, LHL 5050 & 6050 mortice locks, and 85 series mortice locks

Working Temperature: -25C – 60C degrees

Working Humidity: 0% – 95% RH

Door Thickness: 35mm – 65mm

Suitable For: Wooden and metal doors

2 Year Warranty

Introducing the LHL-ED7-B-SEYMOUR Digital Entrance Lock – a cutting-edge security solution from Lion Head Locks! 🔐 Designed for homes, offices, and Airbnbs, the Seymour combines advanced technology with modern design to deliver unparalleled convenience and protection.

With multiple unlocking methods, including PIN code, Bluetooth, fingerprint, Wi-Fi (via gateway), card and manual key, the Seymour offers flexible and secure access for all users. Its durable build ensures long-lasting performance, while its sleek design enhances the style of any entryway.

The Seymour is easy to install, compatible with doors 35mm to 65mm thick, and provides long battery life for worry-free use. Remote access and activity monitoring via the mobile app give you full control, ensuring peace of mind wherever you are.

Upgrade your security with the LHL-ED7-B-SEYMOUR Digital Entrance Lock – the smart, stylish choice for modern access control.

Material: Aluminum alloy

Color: Black

Plate Size: L370 x W70mm x D18mm

Unlocking Ways: APP, Fingerprint, Password, Card, Key

Power Supply: 8pcs AA alkaline batteries

USB Back-Up Power: Yes

Mortise Options: 6068 Anti-theft lock body

Apply Door Thickness: 40~90mm

Working Temperature: -25~60 degree

Applicable For: Wooden or Metal door

The Lion Head Locks RATHDOWNE is modern digital door lock that is suitable for residential and commercial applications.

The RATHDOWNE offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a manual “track style” key in an emergency.

The RATHDOWNE is rated IP55 (outside only), making it suitable for areas with minimal exposure to the elements. It is not recommended for applications that are fully exposed to the elements.

The lock is not supplied with either a latch or lock body, however, its versality allows it to be used with Lion Head Locks tubular latches, LHL 5050 & 6050 series mortice locks & LHL 85 series mortice locks with 45mm, 50mm, 60mm & 70mm backsets. The use of a mortice lock greatly improves the security of the lock.

The RATHDOWNE is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure.

Material: Aluminum alloy

Color: Silver/Black

IP Rating: IP55 (exterior assembly only)

Dimensions: 193mm x 75mm x 22mm

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Doorbell Function: Yes

Supplied Lock/Latch: Not supplied

Lock/Latch Options: LHL tubular latches, LHL 5050 & 6050mortice locks, and LHL 85 series mortice locks with a 45mm, 50mm, 60mm 0r 70mm backset

Working Temperature: -25C – 60C degrees

Working Humidity: -0% – 95% RH

Door Thickness: 35mm to 65mm

Suitable For: Wooden and metal doors

The Lion Head Locks TOORAK is a smart digital keysafe. It is ideal for house keys, car keys, fobs, etc. The TOORAK can be fixed to a wall, a door, or other solid structure. It can also be used like a padlock using the shackle that comes with the unit. This allows it to be used on gates and fences, and anywhere you can secure the shackle.

The TOORAK offers multiple unlocking methods, including via the TTLock APP, Bluetooth, Fingerprint, PIN code and RFID Fob/Card. There is also the option of using a track style override key.

The TOORAK is rated IP55, so it is best suited for applications where there is some protection from the elements.

The TOORAK is simple to use and is easy to program, using the TTLock APP.

The TTLock APP is one of the most popular smart lock applications. It is used in over 200 countries, and it supports more than 30 languages. It is also very secure

Material: Aluminium alloy

Colour: Black

IP Rating: IP65

Dimensions: 135mm (H) x 77.5mm (W) x 45mm (D)

Dimensions (with cover): 140.5mm (H) x 82.5mm (W) x 49mm (D)

Shackle: Yes (included)

Unlocking Methods: APP, Fingerprint, PIN code, Card, Key

User Capacity: 200 Fingerprint, 150 PIN code, 200 Card

Key Override: Yes (track style key)

Batteries: 4 x AA alkaline (not supplied)

Battery Life: Up to 12 months, depending on usage

USB Back Up Power: USB-C port

Working Temperature: -25C – 55℃ degrees

Working Humidity: 20% – 95% RH

Suitable For: Doors, walls, fences, door handles (with shackle) and gates (with shackle)

The HAMILTON by McGrath Locks is a sleek and stylish lock designed for the Australian market. A great addition to the home, office or business, this 5 in 1 digital door lock provides a versatile and convenient method of entry that allows you to easily manage who has access to your property.

Utilising the powerful TTLock App, lock and user settings are easily configured and managed. Access can be provided to family and visitors alike through pin code, RFID credential, eKeys managed via BLE and mechanical key override. By adding a McGrath Locks Wi-Fi gateway you can remotely unlock the HAMILTON from anywhere in the world using the TTLock App.

The HAMILTON is designed with many features for the most demanding applications. It is supplied with an adjustable tubular latch and is also compatible with the most common Australian commercial mortice locks. The lock is fire rated up to 2 hours on E-Core and Firecore doors when installed with the McGrath Locks tubular latch or with a dormakaba MS2602 mortice lock. The Hamilton also has a DDA compliant lever design.

Lock Functions

Manage lock functions via McGrath Locks App using Bluetooth or Wi-Fi (with optional gateway).
Enrol PIN Codes, RFID access cards & tags, Fingerprints, and send eKeys to your family and visitors.
Passage Mode can be used to leave your door open when required.
Anti-peep code function stops unauthorised people from seeing the correct code inputted.
Incorrect attempt lockout after 5 wrong attempts for added security.
Reset button can be disabled in the App for additional security.
Audit trail within the App to see who accessed your door and when.
Mechanical key override option for emergency access.

Battery & Power

Powered by 4 x AA Alkaline batteries (not included).
Low battery alert (visible in App and audible at the lock).
USB-C port for emergency power access.

Built to Last

Glass screen for extra durability.
IP66 weather rated external side for dust and high-pressure water resistance — suitable for outdoor installations where immersion is not expected.

Installation

Field changeable handing for flexible installation.
Retrofittable with DDA compliant levers to comply with BCA AS1428.1 -2009 (Levers sold separately).
Compatible with most common Australian mortice locks.
Suits doors with thickness from 35–54mm.
2-hour fire rating for E-Core and Firecore doors.
Supplied with the ATL6070 McGrath Locks 2-hour fire-rated tubular latch.

Finish & Lock Dimensions

Available in black or satin nickel.
Lock case dimensions: 180mm (H) x 72mm (W) x 25mm (D).

The Ultra-Secua by McGrath Locks is a digital lock designed specifically for screen door applications. A great addition to the home,office or business, this 4 in 1 digital lock provides a versatile and convenient method of entry that allows you to easily manage who has accessto your property. The Ultra-Secua can retrofit most screen door locks on the market including triple locking screen doors. It has been designed with a unique security feature on the inside handle can stop the inside handle being operated through a fly screen.

Utilising the powerful TTLock Bluetooth App, lock and user settings are easily configured and managed. Access can be provided to family and visitors alike through pin code, RFID credential, eKeys managed via BLE and mechanical key override. By adding a McGrath Locks Wi-Fi gateway you can remotely unlock the Ultra-Secua from anywhere in the world using the TTLock App.

The Ultra-Secua has an IP66 rating making it ideal for external applications where a robust solution is required. The lock is supplied with a lock body, key cylinder and batteries to make your installation a breeze.
